Detail
Spherical Lens feature a selection ofplano-convex (PCX), double convex (DCX), plano-concave(PCV), double concave(DCV)and meniscus lenses. Spherical lenses are often used for aiming and focusing ofmonochromatic light source.
| Material | optical glass， BK7， UV quartz，Fluoride series（MgF2/ BaF2/ CaF2） |
| Diameter | 0.6mm-300mm |
| Radius | 2mm-∞ |
| Surface quality | 60-40 or better(custom) |
| Surface irregularity | λ/4-λ/2 @632.8nm or better(custom) |
| Dimension tolerance | ±0.1~±0.02mm |
| Eccentricity | 3'~30'' |
| Clear aperture | >90% |
| Coating | AR, BBAR, AS, AF, ITO, Splitter, Filter, Refector |
